Green Shelf Solar Systems

Green Shelf Solar Systems

The GreenShelf provides significant operational cost-savings, with an impressive ROI, by utilizing solar energy to minimize grid dependence and the reliance on fossil fuels. It is the perfect solution for rural BTS sites. Your solar harvesting will start earlier and last longer than comparable devices on the market. A wind based version is also available.

Key Features & Benefits

  • Widest range of DC input for greatest PV panel flexibility
  • Highest efficiency conversion, more than 97.5%
  • Leading MPPT for maximum panel utilization and solar harvesting
  • Modular design for ease of installation
enquire about this product

Perfect for Off Grid Sites

The GreenShelf provides significant operational cost-savings, with an impressive ROI, by utilizing solar energy to minimize grid dependence and the reliance on fossil fuels. It is the perfect solution for rural BTS sites. Your solar harvesting will start earlier and last longer than comparable devices on the market. A wind-based version is also available.

ModelgreenSHELF V1greenSHELF V2
Termination2x 6mm² tunnel terminalsPhoenix screw terminals
DC Output Nominal Volatge48V DC48V DC
DC Output Max Output Power2.0kW8.0kW
DC Distribution1x load circuit breaker (6-63A)
1x battery circuit breaker (max 63A		1x load circuit breaker (6-63A)
1x battery circuit breaker (max 63A
DC TerminalsLoad: 2x 6mm² rear connect tunnel terminals
Battery: 2x 6mm² rear connect tunnel terminals		DC bulk busbar
Ambient Temprasture-20ºC to +70ºC (maximum output power is derated above +55ºC)-20ºC to +70ºC (maximum output power is derated above +55ºC)
Dimensions (W, H, D)482.6mm (19” mount), 44.45mm (1U), 350.0mm482.6mm (19” mount), 44.45mm (1U), 350.0mm
Weight:5.0kg (excluding solar modules)5.0kg (excluding solar modules)
